ORING IGPS-9084GP-LA Industrial Slim 12-port managed Gigabit PoE Ethernet switch with 8x10/100/1000Base-T(

Link Copied
22,000.00 / piece
Business Type Exporter, Supplier, Distributor, Importer
Type Managed Industrial Ethernet Switch
Shape Rectengular
Application INDUSTRIAL
Click to view more

Product Details

Color
BLACK
Design
Customised
Condition
New
Mechanical Life
1 Year
Brand Name
ORING

IGPS-9084GP-LA is layer2 managed PoE Ethernet switch with 8x10/100/1000Base-T(X) P.S.E. ports and 4x100/1000Base-X SFP ports. The switch support Ethernet Redundancy protocol, O-Ring (recovery time < 20ms over 250 units of connection) and MSTP (RSTP/STP compatible) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. IGPS-9084GP-LA also support Power over Ethernet, a system to transmit electrical power up to 30 watts, total PoE power budget is 240W max, along with data, to remote devices over standard twisted-pair cable in an Ethernet network. IGPS-9084GP-LA switch has 8x10/100/1000Base-T(X) P.S.E. (Power Sourcing Equipment) ports.  P.S.E. is a device (switch or hub for instance) that will provide power in a PoE connection.  And support wide operating temperature from -40 oC to 75 oC.  IGPS-9084GP-LA can also be managed centralized and convenient by Open-Vision, Except the Web-based interface, Telnet and console (CLI) configuration.



  Features
    • Support O-Ring(recovery time < 30ms over 250 units of connection) andMSTP(RSTP/STP compatible) for Ethernet Redundancy
    •
    • Open-Ringsupport the other vendor's ring technology in open architecture
    •
    • O-Chain allow multiple redundant network rings
    •
    • Support standard IEC 62439-2 MRP*note  (Media Redundancy Protocol) function
    •
    • 8 port P.S.E. fully compliant with IEEE802.3at standard, provide up to 30 Watts per port
    •
    • Support PoE on/off scheduled configuration
    •
    • Support PoE alive check and auto reboot fuction
    •
    • Support IPV6 new internet protocol version
    •
    • Support EtherNet/IP™ and Modbus TCP protocol
    •
    • Support IEEE 802.3az Energy-Efficient Ethernet technology
    •
    • Provided HTTPS/SSH protocol to enhance network security
    •
    • Support SMTP client and NTP server protocol
    •
    • Support IP-based bandwidth management
    •
    • Support application-based QoS management
    •
    • Support Device Binding security function
    •
    • Support DOS/DDOS auto prevention
    •
    • Support auto-negotiation and auto-MDI/MDIX
    •
    • Support full and half duplex mode
    •
    • IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic
    •
    • Support SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management
    •
    • Support ACL, TACACS+ and 802.1x User Authentication for security
    •
    • Support 9.6K Bytes Jumbo Frame
    •
    • Syslog/SNMP Trap notification for warning of unexpected event
    •
    • Support DBU-01 backup unit device to quickly backup/restore configuration
    •
    • Web-based ,SNMP v1/v2c/v3, Telnet, Console (CLI), and Windows utility (Open-Vision) configuration
    •
    • Support LLDP Protocol
    •
    • Robust EMS design, provide 8K ESD and 4KV Surge protection
    •
    • Rigid IP-30 housing design
    •
    • DIN-Rail and wall mounting enabled
    *NOTE: This function is available by request only
