ORING IGPS-9084GP-LA Industrial Slim 12-port managed Gigabit PoE Ethernet switch with 8x10/100/1000Base-T(

IGPS-9084GP-LA is layer2 managed PoE Ethernet switch with 8x10/100/1000Base-T(X) P.S.E. ports and 4x100/1000Base-X SFP ports. The switch support Ethernet Redundancy protocol, O-Ring (recovery time < 20ms over 250 units of connection) and MSTP (RSTP/STP compatible) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. IGPS-9084GP-LA also support Power over Ethernet, a system to transmit electrical power up to 30 watts, total PoE power budget is 240W max, along with data, to remote devices over standard twisted-pair cable in an Ethernet network. IGPS-9084GP-LA switch has 8x10/100/1000Base-T(X) P.S.E. (Power Sourcing Equipment) ports.  P.S.E. is a device (switch or hub for instance) that will provide power in a PoE connection.  And support wide operating temperature from -40 oC to 75 oC.  IGPS-9084GP-LA can also be managed centralized and convenient by Open-Vision, Except the Web-based interface, Telnet and console (CLI) configuration.

• • Support O-Ring(recovery time < 30ms over 250 units of connection) andMSTP(RSTP/STP compatible) for Ethernet Redundancy

  • Open-Ringsupport the other vendor's ring technology in open architecture

  • O-Chain allow multiple redundant network rings

  • Support standard IEC 62439-2 MRP*note  (Media Redundancy Protocol) function

  • 8 port P.S.E. fully compliant with IEEE802.3at standard, provide up to 30 Watts per port

  • Support PoE on/off scheduled configuration

  • Support PoE alive check and auto reboot fuction

  • Support IPV6 new internet protocol version

  • Support EtherNet/IP™ and Modbus TCP protocol

  • Support IEEE 802.3az Energy-Efficient Ethernet technology

  • Provided HTTPS/SSH protocol to enhance network security

  • Support SMTP client and NTP server protocol

  • Support IP-based bandwidth management

  • Support application-based QoS management

  • Support Device Binding security function

  • Support DOS/DDOS auto prevention

  • Support auto-negotiation and auto-MDI/MDIX

  • Support full and half duplex mode

  • IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic

  • Support SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management

  • Support ACL, TACACS+ and 802.1x User Authentication for security

  • Support 9.6K Bytes Jumbo Frame

  • Syslog/SNMP Trap notification for warning of unexpected event

  • Support DBU-01 backup unit device to quickly backup/restore configuration

  • Web-based ,SNMP v1/v2c/v3, Telnet, Console (CLI), and Windows utility (Open-Vision) configuration

  • Support LLDP Protocol

  • Robust EMS design, provide 8K ESD and 4KV Surge protection

  • Rigid IP-30 housing design

  • DIN-Rail and wall mounting enabled
  *NOTE: This function is available by request only
