ORING RGPS-R9244GP+-LP Industrial Layer-3 28-port managed Gigabit PoE Ethernet switch with 24x10/100/1000B

Overview

RGPS-R9244GP+ series is Layer 3 Gigabit managed redundant ring PoE Ethernet switch with 24x10/100/1000Base-T(X) IEEE802.3at P.S.E. ports and 4x1G/10GBase-X SFP+ ports.  The switch support Ethernet Redundancy protocol, O-Ring (recovery time < 30ms) and MSTP (RSTP/STP compatible) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology.  RGPS-R9244GP+ series also support Power over Ethernet, a system to transmit electrical power up to 30 watts, along with data, to remote devices over standard twisted-pair cable in an Ethernet network.  Each RGPS-R9244GP+ series switch has 24x10/100/1000Base-T(X) P.S.E. (Power Sourcing Equipment) ports.  P.S.E. is a device (switch or hub for instance) that will provide power in a PoE connection.  And RGPS-R9244GP+ series support wide operating temperature from -40℃ to 60℃.  Besides the Web-based interface, Telnet and console (CLI) configuration, RGPS-R9244GP+ series can also be managed centralized and convenient by Open-Vision. Therefore, the switch is one of the most reliable choice for highly-managed and Fiber PoE Ethernet application

Features

• • Support Layer 3 static routing, RIP and VRRP function

  • Support O-Ring(recovery time < 30ms) andMSTP(RSTP/STP compatible) for Ethernet Redundancy

  • O-Chain allow multiple redundant network rings

  • Supportstandard IEC 62439-2 MRP*note  (Media Redundancy Protocol) function

  • 24 port P.S.E. fully compliant with IEEE802.3at standard, provide up to 30 Watts per port

  • Support PoE on/off scheduled configuration

  • Support PoE alive check and auto reboot fuction

  • Support IPv6 new internet protocol version

  • Support Modbus TCP protocol

  • Support IEEE 802.3az Energy-Efficient Ethernet technology

  • Provided HTTPS/SSH protocol to enhance network security

  • Support SMTP client and SNTP server protocol

  • Support application-based QoS management

  • Support Device Binding security function

  • Support DOS/DDOS auto prevention

  • IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic

  • Support SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management

  • Support ACL and 802.1x User Authentication for security

  • Support 10K Bytes Jumbo Frame

  • SFP socket support DDM function

  • Multiple notification for warning of unexpected event

  • Support DBU-01 backup unit device to quickly backup/restore configuration

  • Web-based ,Telnet, Console (CLI), and Windows utility (Open-Vision) configuration

  • Support LLDP Protocol

  • 19 inches rack mountable design
